Description of this part:

Portable hydraulic motor pump is a kind of small motor pump, it can be used together with rescue tools, can produce large output force. The pump motor is widely used in fire, earthquakes, landslides and highway railway aviation and other disaster accident rescue work. Has the advantages of small volume, light weight, convenient carrying, simple to use, large output force and other characteristics, can fast rescue in the disaster accident injured and trapped, effectively avoid casualties.

1, a hydraulic oil tank

2, the valve board

3, a hand control switch

4, handle

5, the gasoline tank

6, the gasoline engine

7, bracket

8, foot pad

9, turbine oil filling hole

10, the hydraulic oil window

11, the pressure oil output and fast interface

12, a low pressure loop and fast interface

13, the hydraulic oil filling hole

14, a motorized pump bracket

15, a hydraulic oil tank cover

Item	Unit	Specifications
Engine Model	Set	Janpan Honda GXH100 gasoline engine
Rated voltage output pressure	MPa	≥63
Rated high pressure flow rate	L/min	0.1
Low pressure output pressure	MPa	12
Low pressure output flow rate	L/min	0.42
Weight(hydraulic oil,engine oil,gasoline)	kg	25
Recommeded fuel		Unleaded gasoline 90^#-93^#
Recommeded hydraulic oil
